Restyle my chart in the "Car Fleet Age" style described below. Keep my data, chart type, title meaning and units; change only the presentation. Use the charting library this project already uses (plain SVG if there is none). If the library can't express a detail, draw it in a custom layer instead of dropping it. Measurements assume a 960 x 600 chart; scale them proportionally.

Mood: a boxcar side brought indoors. A boxcar-red panel with ribs and rivets carries stenciled white lettering and reporting marks, and a near-black page holds stacked bars that age from pale gray to deep red.

Colors (use these exact values):
- Page: #111111 (near-black).
- Title panel: #9B2C2C (boxcar red), with vertical ribs 6px wide every 74px in #86242A (a 1.5px #B04040 highlight at 60% on their left edge) and rows of 1.8px #86242A rivets every 18px, 7px in from the top and bottom edges.
- Age band ramp, new to old: #D4D4D4 (pale gray), #D9A7A1, #CF6D63, #B0362F, #7A1A1A (deep red).
- Panel text: #FFFFFF, subtitle #F6DCDC. Chart text: #EDEDED; secondary #9A9A9A; gridlines #262626.

Typography (Google Fonts):
- Stardos Stencil 700 only for the title (36px uppercase, stating the finding). The stencil breaks only read at large sizes, so never set it below about 30px; everything smaller uses Barlow Condensed.
- Barlow Condensed 600 for the reporting mark (20px, 4px letter-spacing, e.g. "BMRR 40211"), the bar totals (19px white) and the data block ("FLEET" 14px with 3px letter-spacing, the count 26px, "BLT 1968 TO 2025" 13px 500 with 2px letter-spacing).
- Barlow Condensed for everything else: subtitle 500 16px; category labels 600 17px #EDEDED; legend labels 600 15px; segment values 600 14px; axis labels 500 14px #9A9A9A; small caps notes 600 12.5 to 13px uppercase with 1.6px letter-spacing.

Layout:
- The red panel spans x 32 to 928, y 28 to 160, square corners. Reporting mark, title and subtitle stack on its left; on its right a data block inside a 1.5px white outline (about 164 x 82px): "FLEET", the total count, "BLT 1968 TO 2025".
- A legend row under the panel: "CAR AGE, YEARS" in #9A9A9A, then a 22 x 16px swatch and label per band.
- Category labels right-aligned to x 186, bars from x 200. Footer: "Source: ..." left and an uppercase note right.

Axes and grid:
- Vertical 1px #262626 gridlines at round values behind the bars, labels 500 14px #9A9A9A under the last row. No axis lines.

Marks:
- Bar chart: horizontal stacked bars 27px tall on a 40px row pitch, square corners, segments separated by a 1.5px #111111 stroke, sorted by total. Print segment values when a segment is at least 40px wide (dark #111111 text on the three light bands, white on the two dark bands). Print the total 10px past each bar in Barlow Condensed 600.
- Line chart: one 2.5px line per group using the age ramp colors (or the groups ranked by a single measure in deep red #7A1A1A), dots at each point with a 2px #111111 ring, totals at the right end in Barlow Condensed 600, same red panel.

Avoid: gradients, glow, rounded bars, bright non-red hues, cramming values into thin segments, and setting the stencil face at small sizes, where it reads as a plain serif.

When you're done, render the chart and check that the ramp reads new-to-old from light to dark, the percentage in the title matches the data, the fleet total equals the sum of all bars, and nothing in the red panel collides.
